CO2 & Fiber Laser Cutting Systems For Precision Sheet Metal Processing.

OEM Laser cutting machine series

Double-drive gantry flying optics laser cutting machines, with lightweight bridge optimized for high dynamics & accuracy.
  • LZ-3015/4020/6020: 3x1.5m, 4x2m, 6x2m (1 to 6kW).
  • LH-6025/8025: 6x2.5m, 8x2.5m (3 to 12kW). High power and high dynamics for higher productivity.
  • EX-3015/4020 "Excalibur":  3x1.5m, 4x2m (4 to 12kW).  High power & High Speed. With shuttle table in front, for easy operator access and full overview of the entire process.

Compact Laser Cutting machine Falcon M3015/M4015

  • The PRC Laser Falcon M3015/M4015 is a compact high-dynamic 2D laser cutting machine designed for sheet metal formats of 3m x 1.5m and 4m x 1.5m.
  • Underhanging flying optic gantry on centered X-axis concept for superior dynamics in the cutting process. Aggressive axis movements without loss of accuracy.
  • Designed for Fiber laser beam delivery up to 8000 W.
  • Thanks to this construction, the operator has ergonomic and easy access to the working area inside the machine.

Compact “Small Format” Laser Cutting machine M1212

  • The PRC Laser M1212 is a compact high-dynamic 2D laser cutting machine with a working range of 1.25m x 1.25m
  • With Fiber Laser (500W to 4 kW), or with CO2 laser.
  • Superior Dynamics without compromising the accuracy.
  • Heavy and rigid one single piece machine frame structure, requiring no floor anchoring. Easy installation.
  • Extremely ergonomic semi-automatic loading/unloading system.

Compact “General-Purpose” Laser Processing machine M2.5

  • Compact & Flexible "General-Purpose" laser system,
    with a work station volume of 1.25m x 1m  x 1m(H)
  • Unique concept allows to process various kinds of workpieces, using special fixtures, rotary and/or tilting stations, etc...
  • With CO2 or Fiber laser technology.
    Various laser processing heads for different applications.
  • For laser cutting, welding, cladding, 3D-Printing, etc…

Large Format Laser Cutting series, Stand-alone or in coil-cutting line.

  • ∑F12030-to-36050: Laser cutting machine, with cutting table length from 12m to 36m (in steps of 3m), and width from 3m to 5m (in steps of 0.5m). Fiber laser power from 3 to 12kW.
  • LY12015/LY12025:  Advanced “multiple head” laser cutting machine with compact layout, stand-alone machine or integrated in a coil-cutting production line. 12m x 1.5m/2.5m.
  • Available with up to 3 independent cutting heads, cutting simultaneously, for higher production capacity.
  • Coil-cutting line integration, with special rolling cutting bed.

Learn how our versatile Laser Cutting Systems can be customized to meet your specific fabrication needs.

Contact us today

Our team is ready to help you find innovative solutions for your unique laser application!
